Big roll rewinding machine for adhesive tapes jumbo roll

FOB Reference Price:Get Latest Price
$5,000.00 - $10,000.00 / Set | 1 Set/Sets (Min. Order)
Model Number:
JC-R01
Lead Time:
Quantity(Sets) 1 - 2 3 - 5 >5
Est. Time(days) 20 25 Negotiable
Customization:
Customized logo (Min. Order: 1 Sets)
Customized packaging (Min. Order: 1 Sets)

More

Graphic customization (Min. Order: 1 Sets) Less
Report Suspicious Activity
Overview
Quick Details
Type:
OTHER, Packing Machine
Warranty:
1 YEAR, 1 year
Applicable Industries:
Garment Shops, Manufacturing Plant, Machinery Repair Shops, Printing Shops, Advertising Company
After Warranty Service:
Video technical support, Online support, Spare parts, Field maintenance and repair service
Local Service Location:
INDIA, Mexico, Thailand, malaysia, Sri Lanka, BANGLADESH
Showroom Location:
Mexico, BANGLADESH
Video outgoing-inspection:
Provided
Machinery Test Report:
Provided
Marketing Type:
Ordinary Product
Warranty of core components:
1 YEAR
Core Components:
MOTOR, GEAR
Condition:
New
Application:
APPAREL, BEVERAGE, CHEMICAL, commodity, Food, Machinery & Hardware, Medical, Textiles
Packaging Type:
cartons, case, Film, FOIL
Packaging Material:
wood, plywood
Automatic Grade:
Automatic
Driven Type:
Electric
Voltage:
As required
Power:
5HP
Place of Origin:
Guangdong, China
Brand Name:
JCD
Weight:
1000kg
Dimension(L*W*H):
2.8x1.4x1.5m
Certification:
CE Certificate
After-sales Service Provided:
Field installation, commissioning and training, Engineers available to service machinery overseas
Key Selling Points:
Easy to operate
Function:
rewinding
Speed:
High speed
Operation:
easy to operate
Controlling:
automatic tension controlling
Machine name:
Big rolling rewinding machine for adhesive tapes
Keyword:
Big rolling rewinding machine
Machine type:
Semi Auto
Supply Ability
Supply Ability:
30 Set/Sets per Month
Packaging & Delivery
Packaging Details
Seaworthy plywood case for export.
No need fumigation.
Port
Shenzhen,Guangzhou
Picture Example:
package-img
package-img
Lead Time :
Quantity(Sets) 1 - 2 3 - 5 >5
Est. Time(days) 20 25 To be negotiated
Video Description

  •  NAME :

        Big rolling rewinding machine for adhesive tapes jumbo roll.



  •  FUNCTION :

         This rewinding machine is suitable for rewinding jumbo roll of adhesive tapes, films, papers etc.

         Such as the BOPP Tape, masking tape, protective films,labels, stckers etc.



  •  FEATURES :

1. Main driving mode:

 Synchronous belt and wheel combined.

makes machine with low noise and environmental.

2. Length counter:

Two section length counter , first section to reduce the speed when close to the required length. Second section to stop the rewind steady, ensure accurate rewind length.

3. Rewinding shaft

Air shaft with Automatic air inflation system.

4. Roller

The pneumatic press roller to eliminate film-wrinkle and air -bubble. Ensure the high quality products.

5. Tension control

Magnetic tension control system and brake. Both unwind and rewind tension can be adjusted.



  •  MAIN TECHNICAL PARAMETERS :
Model   1.3M
Effective width  1350mm
Max diameter for unwinding   600mm
I.D of paper core   76.2mm
Max diameter for rewinding   300mm
Max speed for rewinding  150M/Min



  • Optional device for rewinding machine :



1

Separate unloading part .

2

Auto loading device by hydraulic lifter.

3

Noise reduce system:  Add the cover in the unwinding part. That will reduce the noise by 90%, makes the working with low noise and environmental.

4

Automatic Labeling system.

5

Heating device.

6

Cutting function: Able to be equipped with air score knife and trim removable unit for trimming at both sides and wide size slitting.

7

OEM:  OEM service with your own logo or products are available.







Packaging & Shipping
  • Before packing and packing way:
1. Anti rust oil treatment.
2. Put inside Desiccant.
3.Strech film packing outside.
4. Seaworty plywood cace.  No need do the fumigation before shipping.
5.Vacuum packing optional.





Send inquiry---24 hours online !
